FLANGE FOR LIQUID MEMBRANE - (326.300.000 S)
×
![]()
Part Of the Series: Intermediate section
Type no.: 326.300.000 S
EAN no.: 5705499107180
VVS no.: 153585840
FLANGE FOR LIQUID MEMBRANE
-Stainless steel: AISI316L/EN1.4404
| Product Specification | |
|---|---|
| Field of Application | Domestic |
| Material | AISI 316L |
| Material (EN) | EN 1.4404 |
| Minimum Height (mm) | 45 |
| Outlet dia. (mm) | 113 |
| Outlet Diameter (Inch) | 4 |
| Shape | Round |
| Weight (kg) | 0.4 |
| Weight (lbs) | 0.88 |
-
Approval Information
For approval information, please refer to the below approval certificates.
