DOUBLE BRANCH 87.5° - (832.075.110 S)
×
![]()
Part Of the Series: Double branch-87.5-90
Type no.: 832.075.110 S
EAN no.: 5705499402032
RSK no.: 1550375
NRF no.: 2172599
LVI no.: 0254960
DOUBLE BRANCH 87.5°
-Pipe diameter: Ø110mm. Branch diameter: Ø75mm
-Stainless steel: AISI316L/EN1.4404
| Product Specification | |
|---|---|
| Angle (°) | 87.5 |
| Length (mm) | 152 |
| Material | AISI 316L |
| Material (EN) | EN 1.4404 |
| Outlet dia. (mm) | 110 |
| Outlet Diameter (Inch) | 4 |
| Weight (kg) | 0.89 |
| Weight (lbs) | 1.96 |
-
Approval Information
For approval information, please refer to the below approval certificates.
AUS - WMKT00204 - 24
DK - VA 2.12/19349 EuroPipe DS432
NO - 0692-22 EuroPipe
DE - LGA Certificate 57214035 a
HACCP Food Safety Programme - Australasia
US - IAPMO File No.3247-EuroPipe
