SWEPT BRANCH 87.5° - (839.075.075)
×
![]()
Part Of the Series: Swept branch-87.5-long bend
Type no.: 839.075.075
EAN no.: 5705499402575
VVS no.: 160222075
RSK no.: 1550183
NRF no.: 2170091
LVI no.: 0245236
SWEPT BRANCH 87.5°
-Pipe diameter: Ø75mm. Branch diameter: Ø75mm
-Stainless steel: AISI304/EN1.4301
| Product Specification | |
|---|---|
| Angle (°) | 87.5 |
| Length (mm) | 183 |
| Material | AISI 304 |
| Material (EN) | EN 1.4301 |
| Outlet dia. (mm) | 75 |
| Outlet Diameter (Inch) | 3 |
| Weight (kg) | 0.87 |
| Weight (lbs) | 1.92 |
-
Approval Information
For approval information, please refer to the below approval certificates.
HACCP Food Safety Programme - Europe
DK - VA 2.12/19349 EuroPipe DS432
US - IAPMO File No.3247-EuroPipe ABS - LD1716353-PDA DNV - TAP0000023-rev5, Sanitary discharge pipes KR - Type Approval CPH42135-PE001 Lloyds Register LR22419510TA UR - 1055745 Product approval, EuroPipe and Drains Achilles Certificate - 46702-22 RINA -MAC285119XG EuroPipe MARINE - R4547 NATO CODIFICATION SYSTEM PL - Hygienic Certificate - All Products Bureau Veritas, 02375-I0 Pipes & Fittings
