SWEPT BRANCH 87.5° - (839.075.075 S)
×
![]()
Part Of the Series: Swept branch-87.5-long bend
Type no.: 839.075.075 S
EAN no.: 5705499402582
VVS no.: 160222375
RSK no.: 1550384
NRF no.: 2170791
LVI no.: 0255236
SWEPT BRANCH 87.5°
-Pipe diameter: Ø75mm. Branch diameter: Ø75mm
-Stainless steel: AISI316L/EN1.4404
| Product Specification | |
|---|---|
| Angle (°) | 87.5 |
| Length (mm) | 183 |
| Material | AISI 316L |
| Material (EN) | EN 1.4404 |
| Outlet dia. (mm) | 75 |
| Outlet Diameter (Inch) | 3 |
| Weight (kg) | 0.87 |
| Weight (lbs) | 1.92 |
-
Approval Information
For approval information, please refer to the below approval certificates.
DK - VA 2.12/19349 EuroPipe DS432
US - IAPMO File No.3247-EuroPipe
HACCP Food Safety Programme - Europe
