SWEPT BRANCH 87.5° - (839.110.160)

Product Image - Swept branch-89-long bend

Part Of the Series: Swept branch-87.5-long bend

Type no.: 839.110.160

EAN no.: 5705499402636

VVS no.: 160222157

RSK no.: 1550187

NRF no.: 2170132

LVI no.: 0245244

Download CAD Collections

2d DWG files

3d STP files

Download MasterSpec Documents

MasterSpec

SWEPT BRANCH 87.5°
-Pipe diameter: Ø160mm. Branch diameter: Ø110mm
-Stainless steel: AISI304/EN1.4301

Product Specification
Angle (°)	87.5
Length (mm)	258
Material	AISI 304
Material (EN)	EN 1.4301
Outlet dia. (mm)	160
Outlet Diameter (Inch)	6
Weight (kg)	2.53
Weight (lbs)	5.58

Approval Information

For approval information, please refer to the below approval certificates.

DK - VA 2.12/19350 HACCP Food Safety Programme - Europe HACCP Food Safety Programme - Australasia US - IAPMO File No.3247-EuroPipe DK - VA 2.12/19349 EuroPipe DS432 MARINE - R4547 NATO CODIFICATION SYSTEM KR - Type Approval CPH42135-PE001 ABS - LD1716353-PDA Bureau Veritas, 02375-I0 Pipes & Fittings Achilles Certificate - 46702-22 UR - 1055745 Product approval, EuroPipe and Drains Lloyds Register LR22419510TA DNV - TAP0000023-rev5, Sanitary discharge pipes PL - Hygienic Certificate - All Products RINA -MAC285119XG EuroPipe
