LOWER PART - (151.000.075 S)

Part Of the Series: Lower part-110

Type no.: 151.000.075 S

EAN no.: 5705499107128


Download CAD Collections

2d DWG files

3d STP files



Download MasterSpec Documents

MasterSpec

Product Specification
Field of Application Domestic
Material AISI 316L
Material (EN) EN 1.4404
Membrane Type No Membrane
Minimum Height (mm) 263
Number of Inlets 3 (Ø32/40mm)
Number of Inlets (Inch) 3 (Ø1-1/4 inch, 1-1/2 inch)
Outlet dia. (mm) 75
Outlet Diameter (Inch) 3
Outlet Direction Vertical
Weight (kg) 1.4
Weight (lbs) 3.09

Flange
