HYGIENICPRO CHANNEL 150x6000 CENTER OUTLET - (676CT060-30CF S)
Part Of the Series: Channel-No membrane
Type no.: 676CT060-30CF S
EAN no.: 5705499137248
LVI no.: 3305728
Size: 150x6000
HYGIENICPRO CHANNEL 150x6000 CENTER OUTLET
-Low model. With outlet box
-Floor: concrete, tiled and resin
-No membrane
-Outlet: Ø4 inch, horizontal
-Stainless steel: AISI316L/EN1.4404
Product Specification | |
---|---|
Field of Application | Industrial |
Floor | Concrete / Tiled / Resin |
Material | AISI 316L |
Material (EN) | EN 1.4404 |
Membrane Type | No Membrane |
Minimum Height (mm) | 319 |
Outlet Box | Yes |
Outlet dia. (mm) | 110 |
Outlet Diameter (Inch) | 4 |
Outlet Direction | Horizontal |
Outlet Placement | Center |
Shape | Rectangular |
Size (mm) | 150x6000 |
Size of Frame (Inch) | 5-7/8 x 236-1/4 |
Weight (kg) | 50.37 |
Weight (lbs) | 111.05 |
-
Approval Information
For approval information, please refer to the below approval certificates.
