UPPER PART - (710.502.000 S)

Part Of the Series: Upper part-No membrane-205

Type no.: 710.502.000 S

EAN no.: 5705499108293

VVS no.: 153018146

LVI no.: 3303814

Size: Ø205


Download CAD Collections

2d DWG files

3d STP files



Download MasterSpec Documents

MasterSpec

Product Specification
Field of Application Industrial
Floor Resin
Material AISI 316L
Material (EN) EN 1.4404
Minimum Height (mm) 78
Number of Screw Holes 0
Outlet dia. (mm) 110
Outlet Diameter (Inch) 4
Shape Round
Size (mm) Ø205
Size of Frame (Inch) Ø8-1/8
Weight (kg) 1.56
Weight (lbs) 3.44
