LOWER PART - (760.160.110)

Part Of the Series: Lower part-160

Type no.: 760.160.110

EAN no.: 5705499135343

RSK no.: 7121871

NRF no.: 3397187

LVI no.: 3305832


Download CAD Collections

2d DWG files

3d STP files



Download MasterSpec Documents

MasterSpec

Product Specification
Field of Application Industrial
Material AISI 304
Material (EN) EN 1.4301
Membrane Type No Membrane
Minimum Height (mm) 267
Outlet dia. (mm) 110
Outlet Diameter (Inch) 4
Outlet Direction Vertical
Weight (kg) 1.35
Weight (lbs) 2.98
