CHANNEL 150x6000 CENTER OUTLET - (670CH060-30BA)
Part Of the Series: Channel-No membrane
Type no.: 670CH060-30BA
EAN no.: 5705499129519
NRF no.: 3397077
Size: 150x6000
CHANNEL 5-7/8 x 236-1/4 CENTER OUTLET
-Floor: concrete, tiled and resin
-No membrane
-Outlet: Ø4 inch, vertical
-Stainless steel: AISI304/EN1.4301
Product Specification | |
---|---|
Field of Application | Industrial |
Floor | Concrete / Tiled / Resin |
Material | AISI 304 |
Material (EN) | EN 1.4301 |
Membrane Type | No Membrane |
Minimum Height (mm) | 152 |
Outlet Box | No |
Outlet dia. (mm) | 110 |
Outlet Diameter (Inch) | 4 |
Outlet Direction | Vertical |
Outlet Placement | Center |
Shape | Rectangular |
Size (mm) | 150x6000 |
Size of Frame (Inch) | 5-7/8 x 236-1/4 |
Weight (kg) | 40.34 |
Weight (lbs) | 88.93 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
