LOWER PART - (760.160.075)
Part Of the Series: Lower part-160
Type no.: 760.160.075
EAN no.: 5705499138016
RSK no.: 7121870
NRF no.: 3397186
LOWER PART
-No membrane flange
-Outlet: Ø75mm, vertical
-Stainless steel: AISI304/EN1.4301
Product Specification | |
---|---|
Field of Application | Industrial |
Material | AISI 304 |
Material (EN) | EN 1.4301 |
Membrane Type | No Membrane |
Minimum Height (mm) | 256 |
Outlet dia. (mm) | 75 |
Outlet Diameter (Inch) | 3 |
Outlet Direction | Vertical |
Weight (kg) | 1.31 |
Weight (lbs) | 2.89 |
-
Approval Information
For approval information, please refer to the below approval certificates.
