LOWER PART - (774.002.075 S)

Part Of the Series: Lower part-160

Type no.: 774.002.075 S

EAN no.: 5705499111910

LVI no.: 3303790


Download CAD Collections

2d DWG files

3d STP files



Download MasterSpec Documents

MasterSpec

Product Specification
Field of Application Industrial
Material AISI 316L
Material (EN) EN 1.4404
Membrane Type Liquid Membrane
Minimum Height (mm) 267
Outlet dia. (mm) 75
Outlet Diameter (Inch) 3
Outlet Direction Vertical
Weight (kg) 2.87
Weight (lbs) 6.33
