UPPER PART - (774.401.000 S)
×
Part Of the Series: Upper part-No membrane-250
Type no.: 774.401.000 S
EAN no.: 5705499128819
Size: 250x250
UPPER PART
-Floor: concrete and tiled
-Frame: 250x250mm
-Stainless steel: AISI316L/EN1.4404
Product Specification | |
---|---|
Field of Application | Industrial |
Floor | Concrete / Tiled |
Material | AISI 316L |
Material (EN) | EN 1.4404 |
Number of Screw Holes | 0 |
Outlet dia. (mm) | 160 |
Outlet Diameter (Inch) | 6 |
Shape | Square |
Size (mm) | 250x250 |
Size of Frame (Inch) | 9-7/8 x 9-7/8 |
Weight (kg) | 2.54 |
Weight (lbs) | 5.6 |
-
Approval Information
For approval information, please refer to the below approval certificates.
