LOWER PART - (760.160.110 S)
Part Of the Series: Lower part-160
Type no.: 760.160.110 S
EAN no.: 5705499135350
LOWER PART
-No membrane flange
-Outlet: Ø110mm, vertical
-Stainless steel: AISI316L/EN1.4404
Product Specification | |
---|---|
Field of Application | Industrial |
Material | AISI 316L |
Material (EN) | EN 1.4404 |
Membrane Type | No Membrane |
Minimum Height (mm) | 267 |
Outlet dia. (mm) | 110 |
Outlet Diameter (Inch) | 4 |
Outlet Direction | Vertical |
Weight (kg) | 1.35 |
Weight (lbs) | 2.98 |
-
Approval Information
For approval information, please refer to the below approval certificates.
