CHANNEL 400x3000 CENTER OUTLET - (672FK030-15BA)
Part Of the Series: Channel-Vinyl
Type no.: 672FK030-15BA
EAN no.: 5705499130676
Size: 400x3000
CHANNEL 15-3/4 x 118-1/8 CENTER OUTLET
-Floor: vinyl
-Outlet: Ø6 inch, vertical
-Stainless steel: AISI304/EN1.4301
Product Specification | |
---|---|
Field of Application | Industrial |
Floor | Vinyl |
Material | AISI 304 |
Material (EN) | EN 1.4301 |
Minimum Height (mm) | 170 |
Outlet Box | No |
Outlet dia. (mm) | 160 |
Outlet Diameter (Inch) | 6 |
Outlet Direction | Vertical |
Outlet Placement | Center |
Shape | Rectangular |
Size (mm) | 400x3000 |
Size of Frame (Inch) | 15-3/4 x 118-1/8 |
Weight (kg) | 29.72 |
Weight (lbs) | 65.52 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
